Home >>Shuttle Laptop Adapter >>Shuttle enp-2320 Computer Power Supply

enp-2320 Power Supplies - Shuttle enp-2320 Computer Power Supply -- This brand new ENP-2320 shuttle PSU is a , +3.3V 17A, +5V 13A, +12V 16A, , 100% compatible with 250W ATX Enhance ENP-2320A Power Supply, one year warranty, 30-days money back. If you have any question or suggestion about this shuttle enp-2320 Power Supplies, please contact us so we can offer you the most convenient service.

shuttle ENP-2320 power supply for 250W ATX Enhance ENP-2320A Power Supply

Shuttle enp-2320 adapter - New Zealand Store

safe
30 day money back
  • Availability: IN STOCK
  • Pcode :
  • SHU17665_Se
  • AC Input :
  • 100-240V 4-2A VAC Auto Sensing
  • DC Output :
  • +3.3V 17A, +5V 13A, +12V 16A,
  • Connection:
  • 3.2"(W) X 5.9"(L) X 1.7"(H)
  • Type :
  • GSBB0C
  • Condition
  • PSU (Brand new)
  • battery rate
  • SRP Price : NZ $ 161
  • Your Price : NZ $105
nz battery store
band of trust

Shuttle enp-2320 PSU - Product information

  • Tech Specs : AC Input: 100-240V 4-2A VAC Auto Sensing. DC Output: +3.3V 17A, +5V 13A, +12V 16A,
  • Product Type : Brand new, 100% compatible with 250W ATX Enhance ENP-2320A Power Supply.
  • The Shuttle enp-2320 Power Supplies has been tested and validated on shuttle systems.
  • The shuttle enp-2320 AC Adapter features: fits for many shuttle models, fully charge in a short time!
  • Order Shuttle enp-2320 PSU now: Full One year waranty
  • Fit Part Numbers:

Output Wattage 250W
This is an 80 PLUS Bronze Certified: Power Supply Units (PSUs) that have more than 80% energy efficiency at 20%, 50% and 100% of rated load, and a power factor of 0.9 or greater at 100% load. That is, PSUs that waste 20% or less electric energy as heat at the specified load levels, thus reducing electricity use and bills compared to less efficient PSUs.

Dimension: 3.2"(W) X 5.9"(L) X 1.7"(H)
Form Factor: TFX12V
Active PFC/CE, UL/CUL Safety Compliant
Input Voltage: 100-240V 4-2A VAC Auto Sensing
Frequency: 60-50Hz
Holdup Time: > 14ms @ Full Load
MTBF: 100,000 HRS
DC Output: +3.3V 17A, +5V 13A, +12V 16A, -12V 0.3A, +5Vsb 2A
Dimensions: 5.9"x 3.2"x 1.7" (150Lx82Wx43H mm)
Connectors:
1x 20/24 Pin ATX Connector
1x 4-Pin 12V
3x Peripheral Connectors (MOLEX 4 PIN)
1x Power Connector for Floppy Drives.
2x SATA connectors

Replacement/Compatibility Reference:

Achme AM630BS20S
FSP200-50PLA
Shuttle PS-X200W
WIN-200PS (original PS has extra 6 pin auxiliary connector)
Enhance ENP-2320
Enhance ENP-2320A
Enhance ENP-2322B-G
Enhance ENP-2322C
Enhance ENP-0812A



Use this power supply to replace the power in your Shuttle XPC mini-barebones system such as SB61G2, SS51G, SK41G SB51G and many others.
NOTE: If you own the early Shuttle SV25 with the wires coming out the top (long side) of the power supply, this model will not fit in your case.

  • Fit Models:
SOLTEK EQ2000 - 200W PFC
SOLTEK EQ3701M - 200W PFC
Shuttle XPC SB51G/SB51GB - 200W PFC
Shuttle XPC SB52G2 - 200W
Shuttle XPC SB61G2 - 200W PFC
Shuttle XPC SS51G/SS51G1(v2.0) - 200W PFC
Shuttle XPC SS50C - 160W/150W PFC
Shuttle XPC SV24/SV25/FV25 - 150W
Shuttle XPC SN45G - 200W PFC up to 190mm
Shuttle XPC SK41G - 200W PFC
Shuttle XPC SN41G2 - 200W PFC
Shuttle XPC SN41G2B - 200 PFC
Shuttle XPC SS40G - 200W PFC
Shuttle XPC SK41G - 200W PFC
